Overview
Description	2U Single Socket Edge Server
Partner(s)	Supermicro
Processor
CPU	Ampere® Altra® Max Series Processor, 96 to 128 Cores Ampere® Altra® Series Processor, 32 to 80 Cores
Max Socket TDP	Up to 250W
Chassis & Power
Form Factor	2U
Power	Dual CRPS 80 PLUS Titanium Redundant PSUs, 2400/1600/1200/1000W with PMBus 1.2 support
Thermal Fan	3x (80x80x38)
Memory, Expansion & Storage
Memory	16 DIMMs (8-channels, 2DPC) Up to DDR4-3200 Up to 4TB
Storage Bays	12 LFF w/ NVMe
On-board Storage	1x PCIe Gen4 x4, NGFF (22110/2280)
Host/CPU Network	CX4 Lx-EN for 2x 10Gb or 1x 25Gb SFP28
Cabled PCIe	0x Slim-SAS x8
PCIe Gen4 Riser Configs	2x DW GPU, and 1x LP 3x LP
OCP Slots	OCP 3.0, up to PCIe Gen4 x16 (Altra x8 only)
BMC
BMC Support	AST2600
BMC Network	CX4 Lx-EN for 2x 10Gb or 1x 25Gb SFP28
Software
Firmware Support	UEFI: AMI AptioV BMC: OpenBMC
Open Firmware Support	Base code available here

PLATFORM CONFIGURATIONS

2U Mt. Hamilton ARS-520M
